- Place of Origin:Guangdong, China
- Brand Name:OEM
- Model Number:OPP-26
- Input Voltage:24V
- Output Voltage:220~240VAC
- Output Power:992WH
- Output Frequency:50HZ/60HZ
- Output Current:12V10A
- Product name:Portable Power
- Application:Electronic
- Quality:High-quality
- Warranty:24 months
- Output indicator:LED Digital Voltage
- Certificate:CE/FCC/ROHS/MSDS/UN3.3/PSE
- Function:Power Support
- PACKING:Carton Boxes
- Size:428*275*315mm
- MOQ:1pcs
Products Description
Products Description
Product Paramenters
Product Paramenters
Model | GW1100 | |
AC output | Output voltage | 100-120VAC,220-240VAC |
Output waveform | Pure sine wave | |
Rated power | 1100W | |
Power protection | 1200W | |
Frequency range | 50Hz/60Hz±3Hz | |
conversion efficiency | >90% | |
Short circuit protection | There, short circuit removal, automatic release | |
Temperature protection | Temperature over 65 °C Protection | |
Operation mode | Press the AC button (about 1~2S) to switch the machine on and off, and the screen will display the AC mark accordingly. | |
Battery characteristics | Battery Type | 33140-Lithium iron phosphate |
Total Capacity | 310000mAh | |
Battery Energy | 992Wh | |
Combination mode | 4S3P | |
Charging function | Voltage range | Solar (18-23V), adapter (19-24V/5A), vehicle (12~15V) |
Maximum charging power | 200W | |
Solar charging | Built-in MPPT algorithm to improve solar charging efficiency | |
Charging time | 6Hs | |
output characteristics | USB output * 3 | 1*TYPE-C 100W,2*USB-A 5V2.4A,1*USB-A QC 3.0 18W |
12V Output5525 | 12V10A | |
Cigarette lighter output | 12V10A | |
LED lighting | Four gears | Low Bright, Highlight, SOS, Flash mode |
BMS Features | Rated current | 100A |
Protection function | 1. Overcharge protection, 2. Overdischarge protection, 3. Temperature protection, 4. Overcurrent protection, 5. Short circuit protection, 6. SOC calculation | |
Operating noise | Less than 30dB | |
Weight and size | Host weight | 11.1KG |
Host size | 192*192*340(L)mm | |
suit weight | 12Kg |
